Sea Crystal Steel Structure Workshop

Project Detailed Description:

Compared with traditional concrete buildings, steel structure buildings use steel plates or section steel to replace reinforced concrete, which is stronger and more resistant to earthquakes. And because the component can be factory made, site installation, thus greatly reducing the construction period. Due to the reusable steel, it can be greatly reduced the construction waste, and more green environmental protection, so it is widely used in industrial buildings and civil buildings over the world.

Inquiry Now

Quick Details

Items		Specifications
Main Steel Frame	Column	Q235B, Q355B Welded H Section Steel
Main Steel Frame	Beam	Q235B, Q355B Welded H Section Steel
Secondary Frame	Purlin	Q235B C and Z Purlin
	Knee Brace	Q235B Angle Steel
	Tie Rod	Q235B Circular Steel Pipe
	Brace	Q235B Round Bar
	Vertical & Horizontal support	Q235B Angle Steel, Round Bar, or Steel Pipe
Maintenance System	Roof Panel	EPS, Glass Fiber, Rock Wool, Pu Sandwich Panel Corrugated Steel Sheet
Maintenance System	Wall Panel	EPS, Glass Fiber, Rock Wool, Pu Sandwich Panel Corrugated Steel Sheet
Accessories	Window	Aluminum Window, Plastic Steel Window
	Door	Aluminum Door, Rolling Metal Door
	Rainspout	PVC
	Fastener	High Strength Bolts, Normal Bolts, Chemical Bolts
	Ventilation System	Natural Ventilator, Ventilation Shutters
Live Load on Roof		In 120kg Sqm (Color steel panel surrounded)
Wind Resistance Grade		12 Grades
Earthquake-Resistance		8 Grades
Structure Usage		Up to 50 years
Temperature		Suitable temperature -50°C~+50°C
Certification		CE, SGS,ISO9001:2008,ISO14001:2004
Finishing Options		Vast array of colors and textures available

1) Customized design is welcomed.

2) We have an excellent design team. According to the requirements of different projects and clients, we will supply different designs and steel products. In order to give you an exact quotation and drawings, please let us know the following information. We will quote for you promptly.

Steel structure building is built over three members connected to each other by bolts and screws:

Primary members (columns, beams)

Steel columns will be H section steel, square tube steel according to different type of buildings. Steel beams are usually H section steel.

Secondary members (C or Z purlins, bracing...)

Roof and wall sheeting or sandwich panel (EPS, fiberglass wool, PU sandwich panel)

Other building components (Rolling doors, aluminum ally windows, etc.)

The entire primary members and secondary members are designed and fully fabricated including cut-to-length, punching, drilling, welding and performing in the factory before shipping to the site for erection.

At the site, all components are assembled and jointed via nut & bolt connections; thereby reducing the costs and assembly times.

These buildings can be provided with different structural and non-structural additions such as ventilators, doors & windows, trusses, mezzanine floors, canopies, crane, insulation…, based on the customer's requirements.
