Quality A H cage layer chicken cage
1. We can supply both steel structure chicken house and inner full set automatic equipment for both laying hens and broilers.
2. All the steel frame are glavanized steel.
3. Insulation:Glavanized steel sheet+glass wool composited on project sit or use EPS /glasswool sandwich panel.
4. For layer/laying hens:We can supply H type cage(bettery cage) and a type cage, feeding line/drinking line/manure clean system/spray indisfect system are all automatic.
5. For broilers:You can chose feed on floor or on the plastic floor,all the equipment we can supply.
6. We also can disign and supply equipment for you if you want to incubation.
No. | Type | Steel structure poultry house |
Steel structure construction | Material | Main steel structure--Q345/Q235 |
Roof and Wall | Roof for v960 fibreglass sandwich panel, wall for V950 fibreglass sandwich panel | |
Door and Window | Aluminum alloy window;Rolled door | |
Column and Beam | Middle column, Welded H section | |
Purlin | C/Z section steel | |
Frame | Welded H beam and hot rolled steel | |
Surface treatment | Hot-dip galvanized | |
Lifetime | 30-50years | |
Equipments | Feeding system | |
Nipple drinker system | ||
Tunnel ventilation and heating system | ||
Curtain system:Automatic curtain machine | ||
Suspension system with ceiling winch | ||
Ventilation:External damper fan with cone | ||
Usage | Broiler, Chicken, Hens, etc rearing house | |
Design | Customized | |
Warranty | 12-18months | |
Delivery time | 20-35 working days | |
Packing | Steel frame is packed in 40'OT container, Maintenance frame and others are packed in 40'GP or 40'HQ | |
Three types of chicken house designs:
A: Open side. It can save the cost of shed, but can not control the temperature very well.
B: Half open side: you can open the curtain, when climate is good. You can close the curtain, when climate is not good. But this tpye chicken farm building can not be used in cold area.
C: Enclosed chicken house designs: This design can control temperature well and reduce the harm of climate changing to chickens. But the cost is higher.
What cages we supply?
A type | BYC-1 | BYC-2 | BYC-3 | BYC-4 | BYC-5 |
Type | 3tires, 4doors | 3 tires, 5 doors | 3 tires, 5 doors | 4 tires, 4 doors | 4 tires, 5 doors |
Capacity | 96 birds | 120 birds | 120 birds | 128 birds | 160 birds |
Size/door | 0.47*0.54*0.37m | 0.39*0.54*0.37m | 0.44*0.54*0.37m | 0.47*0.54*0.37m | 0.39*0.54*0.37 |
Size/Set Cage | 1.88*2.3*1.5m | 1.98*2.3*1.5m | 2.2*2.3*1.5m | 1.88*2.5*1.8m | 1.98*2.5*1.8m |
Quality check & control
Production Processing & Shipping
